The Dreamstar Elite 550 TV Line Digital Day & Night IR Bullet Camera has one of the highest protection ratings (of IP66) and an illumination range (indoor) of 35 m. This Back-light Compensation capable bullet type camera is one of the finest your money can buy, guaranteed!
- 1/3" Sony Sony Super HAD CCD
- Digital Day/Night by IR Pass Filter
- Resolution of 550 Horizontal Lines
- Backlight Compensation(BLC)
- Built-in F1.2/2.8~11mm Lens with DC Iris Control
- Illumination Range approx.. 30 Meters (Indoor)
- 42 integrated 850nm IR LED"s
- Protection Rating IP66
System Day & Night, NTSC Imager 1/3" CCD, Sony Super HAD Interline Transfer CCD Active picture elements 768(H)x494(v)(380K) Scanning system 525 Lines, 2:1 Interlace Scanning Frequency 15.734KHz(H), 59.94KHz(V) synchronization Internal Min.Illumination 0.3Lux(color) / 0.01 Lux (B&W) Horizontal resolution 550 TVL(color) / 560 TVL(B&W) Shutter Speed 1/60 ~ 100,000sec Signal-to-Noise Ration(S/N Ratio) 48db(AGC off) Automatic Gain Control(AGC) Included Backlight Compensation(BLC) On Wide Dynamic Range(WDR) Yes White Balance AWB / ATW Application range day/ night, security Internal Adjustments EI(ELC/ALC On/Off), BLC On/Off, AGC On/Off, Flicker-less On/ Off Lens F1.2/2.8~11mm DC Iris Lens illumination 42 LED"s 850mm, Integrated light sensor illumination range approx..30m(indoor) Day & Night Yes, IR Pass Filter Video outputs 1Vp-p Composite, 75ohms Supply voltage 12VDC(+/-10%) Power consumption 5.8 W Max Temperature range(Operation) -10"~+50"C Humidity range 10%~90% non - condensing Protection ranting IP66 Housing Aluminum Dimensions(mm) 70?) x 148mm(H)
Dreamstar Elite 550 TVL 42 IR LED Digital Day/Night Bullet Camera SOLD OUT
Vendor: Dreamstar
SKU: DSE-IRB5282-42N
Pickup available at 1515 Matheson Boulevard East
Usually ready in 24 hours
Dreamstar Elite 550 TVL 42 IR LED Digital Day/Night Bullet Camera SOLD OUT
-
1515 Matheson Boulevard East
Pickup availableUsually ready in 24 hours
1515 Matheson Boulevard East
A100
Mississauga ON L4W 2P5
Canada905-602-1382
Need help with choosing the right product?
Click here to reach out to one of our experts.
The Dreamstar Elite 550 TV Line Digital Day & Night IR Bullet Camera has one of the highest protection ratings (of IP66) and an illumination range (indoor) of 35 m. This Back-light Compensation capable bullet type camera is one of the finest your money can buy, guaranteed!
- 1/3" Sony Sony Super HAD CCD
- Digital Day/Night by IR Pass Filter
- Resolution of 550 Horizontal Lines
- Backlight Compensation(BLC)
- Built-in F1.2/2.8~11mm Lens with DC Iris Control
- Illumination Range approx.. 30 Meters (Indoor)
- 42 integrated 850nm IR LED"s
- Protection Rating IP66
System Day & Night, NTSC Imager 1/3" CCD, Sony Super HAD Interline Transfer CCD Active picture elements 768(H)x494(v)(380K) Scanning system 525 Lines, 2:1 Interlace Scanning Frequency 15.734KHz(H), 59.94KHz(V) synchronization Internal Min.Illumination 0.3Lux(color) / 0.01 Lux (B&W) Horizontal resolution 550 TVL(color) / 560 TVL(B&W) Shutter Speed 1/60 ~ 100,000sec Signal-to-Noise Ration(S/N Ratio) 48db(AGC off) Automatic Gain Control(AGC) Included Backlight Compensation(BLC) On Wide Dynamic Range(WDR) Yes White Balance AWB / ATW Application range day/ night, security Internal Adjustments EI(ELC/ALC On/Off), BLC On/Off, AGC On/Off, Flicker-less On/ Off Lens F1.2/2.8~11mm DC Iris Lens illumination 42 LED"s 850mm, Integrated light sensor illumination range approx..30m(indoor) Day & Night Yes, IR Pass Filter Video outputs 1Vp-p Composite, 75ohms Supply voltage 12VDC(+/-10%) Power consumption 5.8 W Max Temperature range(Operation) -10"~+50"C Humidity range 10%~90% non - condensing Protection ranting IP66 Housing Aluminum Dimensions(mm) 70?) x 148mm(H)
