Note: The Royal Dual DSS LNB replaces the discontinued EMP Dual DSS LNB
It is the brand new Royal DSS Dual Output Circular LNBF, used for satellite reception in North America. It fit with 18" dish that has a rectangular shaped LNBF feed bracket (D shaped bracket doesn't fit). It has 0.3dB noise figure that is 8-10% better signal strength than 0.6dB LNBF
- Dual output LNBF
- From the makers of Zinwell LNBF
- Light weight and small size for easy installation
- Covers DSS Ku-band satellite frequencies (12.2-12.75 GHz)
- Low noise figure of 0.3 dB for improved signal reception (specially on weak signal) and low interference
- Voltage-controlled RH/LH switching (13/18 V)
- The feed diameter is a standard 40mm thus allowing this LNB to be mounted effortlessly on almost any offset dish, such as Fortec Star 80,90,100, and 120cm
- Circular type
- Excellent isolation
- Compatible with US direct TV system
- Various input frequency range and L.O. for world wide market
- Excellent D.R.O. stability
- Super compact tooling
- Optional for 23mm feed horn
- Waterproof guaranteed
Specification
- LO Frequency: 11.250 GHz
- Conversion Gain: 56 dB
- Cross Pol. Isolation: 18 dB
- Noise Figure: 0.3 dB
- Input Reflector Type: Offset
- Gain Flatness: +/- 4 dB V.Pol and +/- 3 dB H.Pol
- L.O. Frequency Stability: (+25°C) +/- 500 KHz / (-35°C ~ +60°C) +1.9MHz @-30°C, -1.7MHz @+60°C
- L.O. Phase Noise: (1 KHz Offset) -50 dBc/Hz / (10 KHz Offset) -75 dBc/Hz / (100 KHz Offset) -95 dBc/Hz
- Output Connector: 75Ohm F Type Female
- D.C. Power Supply: 10.5 – 21.5 V
- D.C. Power Consumption: 90 mA (Typ.)
- Polar Switching Voltage: Right-hand: 10.5 ~ 14 V / Left-hand: 15.5~ 20 V
- Operating Temperature: -35°C ~ +60°C
